Sai Axial Flow Fan Blower – Model SAI AF 500-1440

SAI Axial Flow Fan Blower – 1 HP, 500 mm, 1440 RPM

We manufacture, supply, and service high-performance axial flow fan blowers designed for industrial air applications. This 1 HP axial fan delivers high airflow up to 25,000 CMH, ensuring energy-efficient, reliable, and low-noise operation for continuous duty.

Technical Specifications

• Type: Direct Drive Axial Fan

• Power: 1 HP

• Speed: 1440 RPM

• Voltage: 415 V / 3 Phase

• Size: 20” (500 mm)

• Air Flow: 25,000 CMH

• Max. Static Pressure: 100 – 500 Pa

Features

• Compact & lightweight for easy installation

• High air volume at low pressure

• Aerodynamically engineered impellers for efficiency

• Energy-saving design with low power consumption

• Smooth, silent, and vibration-free operation

• Adjustable air flow with blade angle setting

• Available in direct & belt drive options

• Multiple construction materials: MS, SS, Aluminum, FRP

• Suitable for ducted & non-ducted systems

• Reliable performance for continuous operation

Applications

• Industrial ventilation & exhaust systems

• Cooling towers & HVAC systems

• Factory sheds, warehouses & workshops

• Textile, chemical & pharmaceutical industries

• Dust and fume extraction units

• General fresh air circulation in large spaces
